Name: TP-Link Archer C24
SKU: 1419
Availability: OutOfStock

Descripción
Valoraciones 0

TP-LINK Archer C24
Router Wi-Fi de doble banda AC750
Wi-Fi de alta velocidad: el AC750 de doble banda es ideal para transmisión de video HD y descarga de alta velocidad.
Cobertura de gran alcance: las antenas 4 × brindan Wi-Fi de gran alcance y conexiones confiables.
Multimodo 3 en 1: admite enrutador, punto de acceso y extensor de rango para agregar flexibilidad.
Controles parentales: administra cuándo y cómo los dispositivos conectados pueden acceder a Internet.
Red de invitados: proporciona acceso independiente para los invitados mientras protege la red del host.
Transmisión fluida HD: admite IGMP Proxy / Snooping, Bridge y Tag VLAN para optimizar la transmisión IPTV.
Compatible con IPv6: compatible con IPv6 (la última versión 6 del Protocolo de Internet).
Compacto y montable: diseñado para ahorrar espacio y complementar cualquier decoración.

WIRELESS
Standards	Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds	AC750 5 GHz: 433 Mbps (802.11ac) 2.4 GHz: 300 Mbps (802.11n)
WiFi Range	2 Bedroom Houses 4× Fixed Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity	Medium Dual-Band Allocate devices to different bands for optimal performance
Working Modes	Router Mode Access Point Mode Range Extender Mode

HARDWARE
Processor	Single-Core CPU
Ethernet Ports	1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports
Botones	WPS/Reset Button
Power	9 V ⎓ 0.6 A

SEGURIDAD

WiFi Encryption

WEP

WPA

WPA2

WPA/WPA2-Enterprise (802.1x)

Network Security

SPI Firewall

Access Control

IP & MAC Binding

Application Layer Gateway

Guest Network

1× 5 GHz Guest Network

1× 2.4 GHz Guest Network

SOFTWARE
Protocols	IPv4 IPv6
Parental Controls	URL Filtering Time Controls
WAN Types	Dynamic IP Static IP PPPoE PPTP L2TP
Quality of Service	QoS by Device
NAT Forwarding	Port Forwarding Port Triggering DMZ UPnP
IPTV	IGMP Proxy IGMP Snooping Bridge Tag VLAN
DHCP	Address Reservation DHCP Client List Server
DDNS	NO-IP DynDNS
Management	Tether App Webpage

PHYSICAL

Dimensions (W×D×H)

4.5 × 4.2 × 1.0 in

(115 × 106.7 × 24.3 mm)

Package Contents

Wi-Fi Router Archer C24

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

OTHER

System Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)

Certifications

FCC, CE, RoHS

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Storage Temperature: -40℃~60℃ (-40℉ ~140℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

TEST DATA

WiFi Transmission Power

CE:

<20dBm(2.4GHz)

<23dBm(5GHz)

WiFi Reception Sensitivity

5GHz:

11a 54M: -76dBm;

11ac VHT20 MCS8: -71dBm;

11ac VHT40 MCS9: -66dBm;

11ac VHT80 MCS9: -62dBm

2.4GHz:

11g 54M: -76dBm;

11n HT20 MCS7: -73dBm;

11n HT40 MCS7: -71dBm
